• Automatic 2-speed geared head stock
• Extra wide one-piece cast iron bed
• Built-in live tailstock spindle
• Half Carriage & two lamella type tool post

---

- Max. roll turning diameter 800/1000mm
- Distance between centers 2000~6000mm
- Max. load between centers 10tons
- Spindle speeds 0.5-250rpm
- Bed width 1200mm
- Spindle motor AC 51 kW

• Automatic 2-speed geared head stock
• Extra wide one-piece cast iron bed
• Built-in live tailstock spindle
• Half Carriage & two lamella type tool post

---

- Max. roll turning diameter 1000/1200
- Distance between centers 2000~6000mm
- Max. load between centers 16tons
- Spindle speeds 0.5-250rpm
- Bed width 1200mm
- Spindle motor AC 60kW

• Automatic 2-speed geared head stock
• Extra wide one-piece cast iron bed
• Built-in live tailstock spindle
• Half Carriage & two lamella type tool post

---

- Max. roll turning diameter 1600~2200mm
- Distance between centers 3000~15000mm
- Max. load between centers 25tons
- Spindle speeds 0.5~250rpm
- Bed width 2000mm
- Spindle motor AC 80kW

• Automatic 2-speed geared head stock
• Extra wide one-piece cast iron bed
• Built-in live tailstock spindle
• Half Carriage & two lamella type tool post

---

- Max. roll turning diameter 1400/1600
- Distance between centers 2000~6000mm
- Max. load between centers 50tons
- Spindle speeds 0.5-250rpm
- Bed width 1600/2000mm
- Spindle motor AC 100kW

• Automatic 2-speed geared head stock
• Extra wide one-piece cast iron bed
• Built-in live tailstock spindle
• Half Carriage & two lamella type tool post

---

- Max. roll turning diameter 1600/2200mm
- Distance between centers 3000~15000mm
- Max. load between centers 70tons
- Spindle speeds 0.5-250rpm
- Bed width 3000-1500mm
- Spindle motor AC 135kW
