• High precision & oil country lathe
• Large spindle bore *105/172mm
• 2-speed tailstock spindle

---

- Swing over bed 750mm
- Swing over carriage 480mm
- Distance between centers 1000~40000mm
- Max. load between centers 3000/4000mm
- Spindle bore 105/172mm
- Spindle speeds 28~1250/20~900rpm
- Spindle motor 4Px11kW

• Heavy duty productive lathe
• One-piece cast iron bed
• 2-speed tailstock spindle

---

- Swing over bed 900mm
- Swing over carriage 680mm
- Distance between centers 2000~6000mm
- Spindle bore 84mm
- Spindle speeds 12~1120mm
- Spindle motor 4Px15kW

• Heavy duty productive lathe
• One-piece cast iron bed
• 2-speed tailstock spindle

---

- Swing over bed 950mm
- Swing over carriage 680mm
- Distance between centers 2000~6000mm
- Max. load between centers 5000kg
- Spindle bore 84mm
- Spindle speeds 12~1120rpm
- Spindle motor 4Px15kW

• Heavy duty large lathe
• One-piece cast iron bed
• Rotating tailstock spindle

---

- Swing over bed 1000/1120/1320mm
- Swing over carriage 730/850/1020mm
- Distance between centers 1000~8000mm
- Max. load between centers 6000kg
- Spindle bore 105mm
- Spindle speeds 5~900/3~600rpm
- Spindle motor 4Px22kW/6Px22kW

- Swing over bed 750~1320mm
- Swing over carriage 480~940mm
- Distance between centers 2000~8000m
- Max. load between centers 4000~8000kg
- Spindle bore 105mm
- Spindle speeds 3~1250rpm/1~630rpm
- Spindle motor AC 15/18.5, AC 22/26, AC 37/45

• Heavy duty large lathe
• Suitable for machining large work
• One-piece cast iron bed
• Rotating tailstock spindle

---

- Swing over bed 1100-2000mm
- Swing over carriage 800~17000mm
- Distance between centers 2000~16000mm
- Max. load between centers 8000/120000kg
- Spindle bore 84/105mm
- Spindle speeds 8~500/6~375rpm
- Spindle motor 4Px30kW

• Heavy duty large lathe
• Suitable for machining large work
• One-piece cast iron bed
• Rotating tailstock spindle

---

- Swing over bed 1400~3000mm/2200~3000mm
- Swing over carriage 1000~2600mm
- Distance between centers 3000~160000mm
- Max. load between centers 20/40ton
- Spindle bore 105mm
- Spindle speeds 1~120rpm
- Spindle motor 4Px45kW /DC 75kW
